Mass-produced vision solutions - for rapid implementation
Tailorable solution configuration - supports cost optimization
MCU
Infineon AURIX™ TC397，6×32-bit TriCore @300MHz
SoC
Horizon Journey ™ 2
2 × Arm®Cortex®-A53 @1GHz
Dual BPU AI engines, equivalent Computing Power≥4TOPS
Memory
512MB LPDDR4
Storage
| 64MB NOR Flash |
Dimension (L x W x H)
121mm x 77.7mm x 47.5mm
Operating Temperature
-40℃～85℃
Operating Voltage
DC9V~16V
Communication Interface
2 × CAN / CANFD (1 of which supports arbitrary frame wake-up)
Debug Interface
1 × 1000Base-T (J2)
1 × JTAG (TC397XP)
2 × UART (J2)
1 × JTAG (TC397XP)
2 × UART (J2)
Video Input
Built-in one way
Camera
2MP @30fps，FOV 100.3°
Outlet method
Single side cable output
IP Code
IP5X
Technical Documentation
